The Acquity UPC2 Convergence Manager regulates and monitors the incoming flow and pressure of liquid CO2 in the system through these mechanisms:
- Electronically controlled CO2 inlet shutoff valve
- Overpressure protection
- Auxiliary valve for venting the injection loop
- Automated back pressure regulator (ABPR)
Features:
- Co2 Pressure Relief: Monitors CO2 pressure and relieves over pressure that exceeds safe limits by venting it to waste or external CO2 vent.
- CO2 shutoff valve: Turns on and shuts off the CO2 automatically when the system is powered off or when it encounters an error
- CO2 inlet pressure transducer:
- Measurement Range: -124 to 1190 psi
- Resolution: 10 psi
- Accuracy: +/- 30 psi at full scale
- Maximum working pressure: 2000 psi
This Waters Acquity UPC2 Convergence Manager comes expertly refurbished from GenTech Scientific.
