Agilent 1100 binary pump right angle view
Agilent 1100 binary front cover off

Agilent 1100 Binary Pump (G1312A)



  • Agilent 1100 Binary Pump (G1312A)
    • CAN Cable
  • In-House Warranty Coverage


  • Installation & Familiarization
  • Extended Warranty

This Agilent 1100 Binary Pump comes expertly refurbished from GenTech Scientific.


  • Lowest volume capillary connections.
    • Two dual-piston, in-series pumps in one housing for a minimum of bench space and lowest internal and external volume. Only 180 – 480 µl internal volume (without mixer).
  • Low flow.
    • Starting at typically 50 µl/min for reproducible gradients at low flow with solvent degassing.
  • Reliable design.
    • With electronically controlled active inlet-valves for flow rates up to 5.0 ml/min, the Agilent 1100 Binary Pump is also ideally suited to standard-bore chromatography. Floating pistons with path-of-least-resistance principle ensures highest seal lifetime.


  • Flow Precision:
    • <0.3 % RSD (typically <0.15 % RSD)
  • Flow Range:
    • Setpoints from 0.001 to 5.0 ml/min,  in 0.001 ml/min increments
  • Operating range:
    • 0 – 40 MPa (0 – 400 bar, 0 – 5880 psi)
    • Pulsation: <2 % amplitude (typically <1 %) at 1 ml/min isopropanol at all pressures >1 MPa (> 10 bar, >147 psi)
    • Compressibility compensation: User selectable, based on mobile phase compressibility
  • Delay volume:
    • 180 – 480 µl (600-900 µl with mixer) dependent on back pressure
  • Recommended pH range:
    • 1.0 – 12.5. Solvents with pH <2.3 should not contain acids which attack steel
  • GLP Features:
    • Electronic records of maintenance and errors. Early maintenance feedback (EMF) continuously tracks binary pump usage and displays feedback messages if preset limits are exceeded.

Agilent Technologies

Full-Service Reseller

Original Quality at Refurbished Prices! Our refurbished analytical instruments have been expertly restored to meet rigid industry standards. GenTech Scientific’s 60,000 square foot facility stocks an extensive multimillion-dollar inventory. Our knowledgeable sales and service team are committed to help you get the right instrument into your lab. Our commitment extends beyond the sale with our warranty and continued service options.

GenTech Scientific Offers:

How GenTech Refurbishes Used Lab Instruments

Every refurbished instrument we sell undergoes a complete electronics inspection and performance evaluation. The instruments undergo in-depth preventative maintenance procedures that include extensive cleaning, detector maintenance, line and pump flushing. Routine maintenance is also addressed and filters, liners, tubing, etc. are all replaced as needed. A full calibration and data verification is performed ensuring our refurbished laboratory instruments are in excellent working condition.

Our expert service engineers and chemists can install and custom-configure the system to be compliant with the methods you plan to run.
