Proton Trigas Generator



Includes:

  • TriGas T421M Generator
    • Electrical Plug: 230V
  • Flow Rate1 Max 42 SLPM Combined
    • Nitrogen: Max 10 SLPM
    • Dry Air: Max 10 SLPM
    • Zero Air: Max 22 SLPM
  • Output Pressure
    • Nitrogen: 0 to 5.5 barg / 0 to 80 psig
    • Dry Air: 0 to 4.1 barg / 0 to 60 psig
    • Zero Air: 0 to 7.6 barg / 0 to 110 psig
  • Warranty Coverage
  • Financing Available


SKU: GTS-7095 Categories: , , Tag:

Features:

  • Low maintenance
  • Quiet operation
  • System senses demand and adjusts production rate
  • Technologies Employed Nitrogen Separation Membrane
  • Flow Rate1 Max 42 SLPM Combined
    • Nitrogen: Max 10 SLPM
    • Dry Air: Max 10 SLPM
    • Zero Air: Max 22 SLPM
  • Output Pressure
    • Nitrogen: 0 to 5.5 barg / 0 to 80 psig
    • Dry Air: 0 to 4.1 barg / 0 to 60 psig
    • Zero Air: 0 to 7.6 barg / 0 to 110 psig
