What you are buying
A refurbished and warrantied Agilent 1260 Infinity G1314B Variable Wavelength Detector (VWD) VL. It measures absorbance at selected wavelengths, built for standard HPLC data rates rather than the faster fast-HPLC rate of the VL+ variant.
Every unit we sell moves through the GenTech Certified process. Solution Scientists disassemble and inspect each module, replace all consumables and degraded wear components, then tune and calibrate the instrument and verify performance against OEM and published benchmarks using known reference chemicals. The instrument ships with its verification report. A certified-refurbished system gives you that performance without the capital cost or the lead time of a new purchase.
What Agilent says about this platform
Agilent designed the 1260 Infinity Variable Wavelength Detector VL to serve as a cost-effective, high-productivity optical sensor for everyday laboratory applications. Agilent highlights this module for its robust optical path, which utilizes a single Deuterium lamp and a dual-beam design to maintain low baseline noise and drift margins. Supporting standard data acquisition rates up to 55 Hz, the G1314B easily handles the peak widths generated by routine analytical HPLC methods. It stands as a low-maintenance, dependable workhorse featuring electronic flow cell identification, an integrated runtime log, and built-in diagnostic tools optimized to deliver consistent compliance and stable performance for budget-conscious laboratories.
What each module does
Variable wavelength detection
Measures absorbance at selected wavelengths, over a range of roughly 190 to 600 nm, at data rates up to 13 Hz. It drops into a compatible 1260 Infinity HPLC stack under OpenLab CDS or ChemStation.
Rather than supporting ultra-high-speed spectral scanning, the Agilent G1314B operates as a dedicated, single-channel ultraviolet-visible (UV-Vis) optical detector within a High-Performance Liquid Chromatography (HPLC) stack. Positioned directly inline after the column compartment, its primary job is to measure the absorbance of eluting components at a single, user-selected wavelength. This process executes several critical system-wide functions:
- Routine Compound Quantitation: It focuses a targeted ultraviolet light path through the flow cell to measure sample concentrations with linear precision across a broad concentration range.
- Compensates for Ambient Fluctuations: It directs a portion of the source beam to a reference photodiode, actively compensating for lamp energy fluctuations to keep the baseline steady.
- Simplified Method Development: It allows the operator to dynamically change the target wavelength via time-programmed steps throughout a single run, optimizing response factors for different peaks.
- Automated Device Tracking: It interfaces with the rest of the 1200 or 1260 series stack to record lamp ignition cycles and flow cell runtime metrics, simplifying GLP routine auditing.
| In this listing | |
| Agilent 1260 VWD VL with standard flow cell G1314B | Verified |
| Warranty Coverage Extended Warranty Options Available | Included |
| Each module is individually serialized and performance-verified before the stack is assembled and tested as a complete system. | |
Technical detail
| Detectior Type | Variable Wavelength Detector VL (VWD VL) |
| Wavelength range | 190 to 600 nm (single channel) |
| Light Source | Deuterium lamp, Double-beam photometer |
| Maximum data rate | up to 55 Hz |
| Wavelength Accuracy | ± 1 nm |
| Baseline Noise / drift | < ± 0.75 x 10⁻⁵ AU (at 230 nm) |
| Flow Cell Capacity | Standard: 14 µL (40 bar pressure limit) |
*OEM specifications for brand new instrument.
What “GenTech Certified” means
Refurbishment at GenTech is a defined process, not a wipe-down. Every system moves through the same specific stages.
1. Disassembly and rebuild. Solution Scientists strip the instrument down, clean each module inside and out, and rebuild it from the frame up. They replace pump seals, pistons, and check valves to specification.
2. Configuration and new parts. Solution Scientists install the options and modules you selected and fit new wear parts throughout. They replace the detector lamp with a new one and reset the lamp hours.
3. Diagnostic and performance testing. Solution Scientists tune and calibrate the instrument, run system diagnostics, and confirm detector wavelength accuracy. They test full-system pressure and gradient performance against OEM and published benchmarks using known reference chemicals.
4. Delivery and installation. The instrument ships in protective packing with a one-year warranty option and professional installation available from a GenTech Solution Scientist.
Labs that run this system
The 1260 HPLC is method-compatible across the techniques most regulated and research labs run every day. These are the application areas buyers ask about most.
Routine Batch Release and Dissolution Profiling
Pharma manufacturing labs deploy the G1314B for high-volume, repetitive quality control testing of finished solid dosage forms. The straightforward optical assembly delivers highly consistent peak areas, ensuring seamless regulatory compliance for routine assays.
Consistent Screening of Target Organic Runoff
Environmental facilities use this variable wavelength detector to track known target contaminants such as phenols or specific industrial waste byproducts. Strong linearity across high concentration ranges allows for accurate everyday quantitative tracking.
Dedicated Assays for Common Additives and Preservatives
Food safety laboratories use the 1260 VWD VL to monitor standard ingredients like benzoic acid, sorbic acid, and caffeine in beverages. The 55 Hz acquisition rate plots reliable curves for everyday high-volume production screenings.
Economical Routine Potency Testing Loops
Boutique cannabis testing labs utilize this robust detector to run cost-effective, everyday potency screenings of primary cannabinoids. High hydraulic reliability ensures consistent calibration curves without the overhead costs of higher-end spectral modules.
Bulk Chemical and Illicit Compound Verifications
Crime laboratories apply the G1314B to verify bulk chemical identities and cutting agents in seized street materials. The simplified optical path provides the clear, uncompromised raw data signatures required to confidently support legal chain-of-custody documentation.
| Weight | 25 lbs |
|---|---|
| Dimensions | 24 × 24 × 24 in |
| Condition | Refurbished |
| Model | G1314B |
| OEM | Agilent Technologies |
| Financing | Financing Options Available |
