What you are buying
A refurbished Agilent 6140 Single Quadrupole LC/MS with a 1200 HPLC front end. The 1200 pump and sampler separate the mixture and deliver a reproducible gradient to the source. The 6140’s ion source converts the eluent into gas-phase ions. The single quadrupole confirms target compounds by mass alongside the chromatographic peak. GenTech rebuilds and tests the LC, the source, and the analyzer, then verifies the system end to end.
Every unit moves through the GenTech Certified process. Solution Scientists disassemble and inspect each module, replace all consumables and degraded wear components, then tune and calibrate the instrument and verify performance against OEM and published benchmarks using known reference chemicals. The instrument ships with its verification report. A certified-refurbished system gives you that performance without the capital cost or the lead time of a new purchase.
What Agilent says about this platform
Agilent built the 6140 around an orthogonal pneumatic nebulizer design, which reduces chemical noise across a wide range of LC conditions. A high-capacity solvent drying system, with user-controlled gas flow rate and temperature, further cuts chemical noise and lets the instrument handle thermally sensitive compounds. Scan speed reaches up to 10,000 atomic mass units per second in fast mode. Mass accuracy holds to within 0.13 u across the calibrated range in scan mode, over a mass range of roughly m/z 10 to 1,350. An optional multimode source runs electrospray and atmospheric pressure chemical ionization at the same time. Fraction collection can trigger on mass, an analog signal, or time, monitoring up to 16 m/z values with the optional I/O Accessory Module installed. Agilent ChemStation Workstation software controls acquisition, analysis, and automation.
What each component does
Liquid chromatograph
Separates the mixture and delivers a reproducible gradient to the source. The 1200 front end runs the same pumps and samplers as a standalone HPLC.
Ion source
An orthogonal pneumatic nebulizer and high-capacity solvent drying system convert the liquid eluent into gas-phase ions while keeping chemical noise low.
Mass analyzer
A single quadrupole filters ions by mass for confirmation, scanning up to 10,000 amu per second in fast mode.
| In this stack | |
| Agilent 6140 Single Quadrupole MS G6140A | Verified |
| Agilent 1200 HPLC Front End | Verified |
| Mechanical Pump | Verified |
| Workstation with preloaded software | Included |
| Each module is individually serialized and performance-verified before the stack is assembled and tested as a complete system. | |
Technical detail
| Scan speed | Up to 10,000 amu/sec (fast mode) |
| Mass accuracy | ±0.13 u (calibrated range, scan mode) |
| Mass range | m/z 10 to 1,350 |
| Software | MassHunter |
| Max pressure | 400 bar |
| Pump options | Isocratic, binary, quaternary |
*OEM specifications for brand new instrument.
What “GenTech Certified” means
Refurbishment at GenTech is a defined process, not a wipe-down. Every system moves through the same five stages.
1. Disassembly and rebuild. Solution Scientists strip the instrument down, clean each module inside and out, and rebuild it from the frame up. They replace pump seals, pistons, and check valves to specification.
2. Configuration and new parts. Solution Scientists install the options and modules you selected and fit new wear parts throughout. They replace the detector lamp with a new one and reset the lamp hours.
3. Diagnostic and performance testing. Solution Scientists tune and calibrate the instrument, run system diagnostics, and confirm detector wavelength accuracy. They test full-system pressure and gradient performance against OEM and published benchmarks using known reference chemicals.
4. Data package you approve before shipment. The verification data goes to you for approval before the system leaves the bench. You see exactly how the instrument performs before it ships.
5. Delivery and installation. The instrument ships in protective packing with a one-year warranty option and professional installation available from a GenTech Solution Scientist.
Labs that run this system
The 6140 is method-compatible across the techniques most regulated and research labs run every day. These are the application areas buyers ask about most.
PFAS testing
EPA Method 537.1 and similar state programs require quantitation of per- and polyfluoroalkyl substances in drinking water at low parts-per-trillion levels, a sensitivity range triple quadrupole MS is built to reach.
Pesticides and mycotoxins
Multi-residue pesticide panels and mycotoxin screens in food and cannabis testing often cover more than 100 compounds in a single run, each requiring the selectivity a triple quadrupole provides against a complex matrix background.
Trace impurities and cleaning validation
Pharmaceutical cleaning validation protocols confirm that equipment surfaces carry no detectable residue of the previous product, often down to sub-part-per-billion swab or rinse limits.
Quantitative toxicology
Forensic and clinical toxicology panels quantify drugs and metabolites in blood, urine, or tissue against legally defensible limits, where a triple quadrupole’s selectivity rules out false positives from matrix interferences.
GLP-grade quantitation
Good Laboratory Practice studies require documented, audit-ready quantitation with full method validation, a standard regulated bioanalysis labs run routinely on triple quadrupole platforms.
| Weight | 200 lbs |
|---|---|
| Dimensions | 24 × 24 × 24 in |
| Model | 6140 |
| OEM | Agilent Technologies |
| Condition | Refurbished |
| Financing | Financing Options Available |
Financing Options Available. Finance Builder.
Need a main board instead?
Replacing a failed pump or looking to upgrade your mass spec? Every module in this system is available individually, in stock and performance-verified.
