What you are buying
A refurbished Agilent 6490 Triple Quadrupole mass spectrometer. This listing is the bare MS; a compatible HPLC front end is sold separately or paired at the bench. The 6490’s iFunnel ion source converts the LC eluent into gas-phase ions with high efficiency. The triple quadrupole isolates a precursor, fragments it, and measures the product ion at trace levels. GenTech rebuilds and tests the source and the analyzer, then verifies the instrument against reference standards.
Every unit moves through the GenTech Certified process. Solution Scientists disassemble and inspect each module, replace all consumables and degraded wear components, then tune and calibrate the instrument and verify performance against OEM and published benchmarks using known reference chemicals. The instrument ships with its verification report. A certified-refurbished system gives you that performance without the capital cost or the lead time of a new purchase.
What Agilent says about this platform
Agilent built the 6490 around iFunnel technology, combining Jet Stream thermal gradient focusing, a hexabore capillary, and a dual ion funnel to carry more ions from the source into the analyzer. A curved collision cell steers ions away from neutral background noise before they reach the second quadrupole. Agilent reports sensitivity down to the attogram level for well-behaved compounds. MassHunter Workstation software runs acquisition, qualitative analysis, and quantitative analysis.
What each module does
iFunnel ion source
Converts the liquid eluent into gas-phase ions. Jet Stream, a hexabore capillary, and a dual ion funnel work together to carry more ions into the analyzer than a conventional source.
Mass analyzer
Two quadrupoles flank a curved collision cell that steers ions away from neutral background noise. The first selects a precursor, the cell fragments it, and the second measures a product ion at trace levels.
Vacuum and detection
Stages the ions from atmosphere to high vacuum, then counts them at the detector.
| In this stack | |
| Triple Quadrupole MS G6490A | Verified |
| 1260 Vialsampler G7129A | Verified |
| 1260 Multicolumn Thermostat G7116A | Verified |
| 1260 Diode Array Detector G7115A | Verified |
|
Workstation loaded with software
|
Included |
| Each module is individually serialized and performance-verified before the stack is assembled and tested as a complete system. | |
Technical detail
| Ion sources | iFunnel (Jet Stream + dual ion funnel) |
| Collision cell | Curved, off-axis noise rejection |
| Sensitivity | To the attogram level (Agilent-reported) |
| Software | MassHunter |
| HPLC front end | Sold separately; commonly 1200/1260/1290 |
*OEM specifications for brand new instrument.
What “GenTech Certified” means
Refurbishment at GenTech is a defined process, not a wipe-down. Every system moves through the same five stages.
1. Disassembly and rebuild. Solution Scientists strip the instrument down, clean each module inside and out, and rebuild it from the frame up. They replace pump seals, pistons, and check valves to specification.
2. Configuration and new parts. Solution Scientists install the options and modules you selected and fit new wear parts throughout. They replace the detector lamp with a new one and reset the lamp hours.
3. Diagnostic and performance testing. Solution Scientists tune and calibrate the instrument, run system diagnostics, and confirm detector wavelength accuracy. They test full-system pressure and gradient performance against OEM and published benchmarks using known reference chemicals.
4. Data package you approve before shipment. The verification data goes to you for approval before the system leaves the bench. You see exactly how the instrument performs before it ships.
5. Delivery and installation. The instrument ships in protective packing with a one-year warranty option and professional installation available from a GenTech Solution Scientist.
Labs that run this system
The 6490 is method-compatible across the techniques most regulated and research labs run every day. These are the application areas buyers ask about most.
PFAS testing
EPA Method 537.1 and similar state programs require quantitation of per- and polyfluoroalkyl substances in drinking water at low parts-per-trillion levels, a sensitivity range triple quadrupole MS is built to reach.
Pesticides and mycotoxins
Multi-residue pesticide panels and mycotoxin screens in food and cannabis testing often cover more than 100 compounds in a single run, each requiring the selectivity a triple quadrupole provides against a complex matrix background.
Trace impurities and cleaning validation
Pharmaceutical cleaning validation protocols confirm that equipment surfaces carry no detectable residue of the previous product, often down to sub-part-per-billion swab or rinse limits.
Quantitative toxicology
Forensic and clinical toxicology panels quantify drugs and metabolites in blood, urine, or tissue against legally defensible limits, where a triple quadrupole’s selectivity rules out false positives from matrix interferences.
GLP-grade quantitation
Good Laboratory Practice studies require documented, audit-ready quantitation with full method validation, a standard regulated bioanalysis labs run routinely on triple quadrupole platforms.
| Weight | 350 lbs |
|---|---|
| Dimensions | 30 × 30 × 30 in |
| Model | 6490 |
| OEM | Agilent Technologies |
| Financing | Financing Options Available |
Financing Options Available. Finance Builder.
Need a main board instead?
Replacing a failed pump or looking to upgrade your mass spec? Every module in this system is available individually, in stock and performance-verified.
